Circuit breaker DPX³ 630,3 poles, with rated current of 630A and thermal magnetic protection.

Rs. 57,520.00 + 18% GST Rs. 69,000.00
17
Low stock: 10 left
Quantity:
>

🚚 Item will be delivered on or before

Sku: DPX³ 422499
Visa Mastercard American Express UPI

Technical characteristics

Rated permanent current Iu 320 A
Rated voltage (Min-Max) 220-690 V
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 36 kA
Overload release current setting (Min-Max) 128-320 A
Adjustment range short-term delayed short-circuit release (Min-Max) 192-3200 A
Adjustment range undelayed short-circuit release (Min-Max) 5000-5000 A
Device construction Built-in device fixed built-in technique
Integrated earth fault protection No
Type of electrical connection of main circuit Screw connection
Suitable for DIN rail (top hat rail) mounting No
DIN rail (top hat rail) mounting optional No
Vendor INDUSWELL
Type Industrial & Scientific
Sku DPX³ 422499
Weight 0.45 kg
