CR-M2SFB

Rs. 260.00 + 18% GST Rs. 520.00
50
Low stock: 10 left
Quantity:
>

🚚 Item will be delivered on or before

Sku: 1SVR405651R1400
Visa Mastercard American Express UPI
EAN:
4013614499067
Minimum Order Quantity:
240 piece
Customs Tariff Number:
85366990

Popular Downloads

Dimensions

Product Net Width:
30.3 mm
Product Net Height:
66.7 mm
Product Net Depth / Length:
29 mm
Product Net Weight:
0.043 kg

Technical

Rated Operational Voltage:
250 V AC
Terminal Type:
Fork
Screw Terminals
Rated Operational Current AC-12 (Ie):
(230 V) 7 A
Rated Insulation Voltage (Ui):
4 V
Mounting Position:
1
Standards:
CAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61984
UL 508

Technical UL/CSA

Connecting Capacity Main Circuit UL/CSA:
Flexible with Ferrule 2x 20-16 AWG
Rigid 2x 20-14 AWG
Stranded 2 x 20-14 AWG
Flammability According to UL94:
V-2

Environmental

Ambient Air Temperature:
Operation -40 ... +70 °C
Storage -40 ... +70 °C
Maximum Operating Altitude Permissible:
2000 m

Material Compliance

Conflict Minerals Reporting Template (CMRT):
RoHS Information:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Certificates and Declarations

Container Information

Package Level 1 Units:
box 10 piece
Package Level 1 Width:
63 mm
Package Level 1 Depth / Length:
153 mm
Package Level 1 Height:
68 mm
Package Level 1 Gross Weight:
0.458 kg
Package Level 1 EAN:
4013614489020
Package Level 2 Units:
240 piece
Package Level 2 Width:
275 mm
Package Level 2 Depth / Length:
335 mm
Package Level 2 Height:
225 mm
Package Level 2 Gross Weight:
12.108 kg
Package Level 2 EAN:
4013614505737

External Classifications and Standards

Object Classification Code:
K
ETIM 7:
EC001456 - Relay socket
ETIM 8:
EC001456 - Relay socket
ETIM 9:
EC001456 - Relay socket
eClass:
V11.0 : 27371603
UNSPSC:
39122335
Vendor INDUSWELL
Type Industrial & Scientific
Sku 1SVR405651R1400
Weight 0.045 kg
