MCB DP 16A 1000V DC 6kA

Rs. 2,710.00 + 18% GST Rs. 4,000.00
32
Low stock: 10 left
Quantity:
>

🚚 Item will be delivered on or before

Sku: BK2016DC
Visa Mastercard American Express UPI
General
Short Description
MCB DP 16A 1000V DC 6kA
Conformity to Standard
IEC 60947-2
Frame
4 Module
Electrical Characteristics
Operational Frequency (Hz)
50Hz/ 60Hz
Rated breaking capacity
6kA
Rated impulse withstand voltage (Uimp)
6kV
Rated insulation voltage (Ui)
500V
Rated operational voltage (Ue)
1000V
Tripping Characteristic
C Curve
Termination capacity
35 mm2 (Rigid) 25 mm2 (Flexible)
Environmental Conditions
IP Rating
IP20
Life
Electrical life-Operating Cycles
3000
Mechanical life-Operating Cycles
100000
Physical Dimensions
Height
87.3
Width
70
Depth
74.5
Vendor INDUSWELL
Type Industrial & Scientific
Sku BK2016DC
Weight 0.45 kg
