Modular Contactor 63A 2NO 2NC

Rs. 9,710.00 + 18% GST Rs. 11,000.00
12
Low stock: 10 left
Quantity:
>

🚚 Item will be delivered on or before

Sku: AUMC2206303
Visa Mastercard American Express UPI
General
Short Description
Modular Contactor 63A 2NO 2NC
Conformity to Standard
IEC 60947-4-1, IEC 60947-5-1
Poles
2NO + 2NC
Frame
3 Module
Electrical Characteristics
Operational Frequency (Hz)
50Hz
Rated Current
(AC-1) 63A
Rated impulse withstand voltage (Uimp)
4kV
Rated insulation voltage (Ui)
440VAC
Rated operational voltage (Ue)
230VAC
Long Description
Modular contactors provide remote switching and automatic control of electric devices and
equipment used in residential and commercial spaces
Main/Acc/Spare
Main Unit
Termination capacity
Main circuit : 25 mm2 (Rigid) 16 mm2 (Flexible) Control Circuit : 2.5 mm2 (Flexible)
Environmental Conditions
IP Rating
IP20
Life
Electrical life-Operating Cycles
1,00,000
Physical Dimensions
Height
85
Width
53.5
Depth
60
Vendor INDUSWELL
Type Industrial & Scientific
Sku AUMC2206303
Weight 0.45 kg
