| Range | ComPacT |
|---|---|
| Range of product | ComPact NSX100...250 ComPacT NSX100...250 ComPact NSX400...630 ComPacT NSX400...630 ComPact NSX100...250 DC ComPacT NSX100...250 DC ComPact NSX100...250 DC PV ComPacT NSX100...250 DC PV ComPact NSX400...630 DC ComPacT NSX400...630 DC ComPact NSX400...630 DC PV ComPacT NSX400...630 DC PV Easy UPS 3S Galaxy VM Galaxy VS |
| Device short name | MX |
| Product or component type | Voltage release |
| Device application | Control |
| Range compatibility | Easy UPS 3S Galaxy VM Galaxy VS |
| Voltage release type | Opening coil Shunt trip release |
| [Uc] control circuit voltage | 24 V DC |
| Range compatibility | ComPacT ComPacT NSX ComPacT ComPacT NSX DC ComPact ComPact NSX ComPact ComPact NSX DC EasyPact EasyPact CVS PowerPact PowerPact Multistandard |
| Operating threshold | 0.7...1.1 x Un opening |
|---|---|
| Response time | 50 ms |
| Control signal type | Impulse Maintained |
| Impulse duration | >= 20 ms |
| Supply inrush power | 10 W |
| Auxiliary connection terminal | Spring 0.5…1.5 mm² (AWG 20...AWG 16) |
| Wire stripping length | 7 mm |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.500 cm |
| Package 1 Width | 4.700 cm |
| Package 1 Length | 6.300 cm |
| Package 1 Weight | 115.900 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 7.300 cm |
| Package 2 Width | 10.800 cm |
| Package 2 Length | 24.800 cm |
| Package 2 Weight | 1.197 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 60 |
| Package 3 Height | 30.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 7.582 kg |
| Warranty (in months) | 18 |
|---|
| Vendor | INDUSWELL |
|---|---|
| Type | Industrial & Scientific |
| Sku | LV429390 |
| Weight | 0.5 kg |
