MX shunt trip release, Compact NSX, PowerPact Multistandard, EasyPact CVS, rated voltage 250 VDC

Rs. 4,120.00 + 18% GST Rs. 8,000.00
49
Low stock: 10 left
Quantity:
>

🚚 Item will be delivered on or before

Sku: LV429394
Visa Mastercard American Express UPI
Main
Range ComPacT
Range of product ComPact NSX100...250
ComPacT NSX100...250
ComPact NSX400...630
ComPacT NSX400...630
ComPact NSX100...250 DC
ComPacT NSX100...250 DC
ComPact NSX100...250 DC PV
ComPacT NSX100...250 DC PV
ComPact NSX400...630 DC
ComPacT NSX400...630 DC
ComPact NSX400...630 DC PV
ComPacT NSX400...630 DC PV
Device short name MX
Product or component type Voltage release
Device application Control
Voltage release type Opening coil
Shunt trip release
[Uc] control circuit voltage 250 V DC
Range compatibility ComPacT ComPacT NSX
ComPacT ComPacT NSX DC
ComPact ComPact NSX
ComPact ComPact NSX DC
EasyPact EasyPact CVS
PowerPact PowerPact Multistandard
Complementary
Operating threshold 0.7...1.1 x Un opening
Response time 50 ms
Control signal type Maintained
Impulse
Impulse duration >= 20 ms
Supply inrush power 10 W
Auxiliary connection terminal Spring 0.5…1.5 mm² (AWG 20...AWG 16)
Wire stripping length 7 mm
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 4.5 cm
Package 1 Width 4.7 cm
Package 1 Length 6.2 cm
Package 1 Weight 116.0 g
Unit Type of Package 2 BB1
Number of Units in Package 2 10
Package 2 Height 7.1 cm
Package 2 Width 10.5 cm
Package 2 Length 23.6 cm
Package 2 Weight 1.219 kg
Unit Type of Package 3 S03
Number of Units in Package 3 60
Package 3 Height 30.0 cm
Package 3 Width 30.0 cm
Package 3 Length 40.0 cm
Package 3 Weight 7.698 kg
Contractual warranty
Warranty (in months) 18
Vendor INDUSWELL
Type Industrial & Scientific
Sku LV429394
Weight 0.8 kg
