RPS120-48-CE DIN RAIL MOUNT 120W POWER SUPPLY

Rs. 2,778.00 + 18% GST Rs. 4,500.00
38
Low stock: 10 left
Quantity:
>

🚚 Item will be delivered on or before

Sku: RPS120-48-CE
Visa Mastercard American Express UPI
Input Voltage 90 - 264 VAC (127 - 370 VDC)
Input Frequency 50/60 Hz
Inrush Current < 48 Amps; Measured at 264 VAC, 25°C Ambient, Cold start
Output Voltage 12V to 48V
Output Power 120 W
Voltage Tolerance ± 1 %
Line Regulation < 1% of Vout
Load Regulation ± 1 %
Turn On Time < 1 sec @ 230 VAC & < 3 sec @ 115 VAC, Full load
Hold Up Time ≥60ms at 230V AC & ≥15ms at 115V AC, Full load
Rise Time < 100 ms
Overload Protection > 110% of rated output current; Hiccup type; Autorecovery
Overvoltage Protection Latched type; Input AC power to be recycled to recover the power supply
Output Short Circuit Protection Hiccup mode when output is shorted; Autorecovery type
Operating Temperature - 25°C to + 70°C; De-rate linearly above 50°C from 100 % load at 50°C to 50 % load at 70°C,- 25°C to 0°C start-up is guaranteed with specification deviation
Storage Temperature - 40°C to + 85°C
Cooling Natural convection cooled
Humidity 5 to 95 % RH, Non condensing
Altitude 2000 m
Dimension 43 x 109.8 x 102.7 mm (W x H x D)
Weight 350 gms
Mounting 35 mm Din rail
Vendor INDUSWELL
Type Industrial & Scientific
Sku RPS120-48-CE
Weight 0.15 kg
