RPS40-24-CE DIN RAIL MOUNT 40W POWER SUPPLY

Rs. 2,133.00 + 18% GST Rs. 4,000.00
47
Low stock: 10 left
Quantity:
>

🚚 Item will be delivered on or before

Sku: RPS40-24-CE
Visa Mastercard American Express UPI
Input Voltage 90 - 264 VAC (127 - 370 VDC)
Input Frequency 50/60 Hz
Inrush Current < 60 Amps; Measured at 264 VAC, 25°C Ambient, Cold start
Output Voltage 12 V to 48 V
Output Power 40 W
Voltage Tolerance ± 1 %
Line Regulation ± 1 %
Load Regulation ± 1 %
Turn On Time < 1 sec @ 230 VAC & < 3 sec @ 115 VAC, Full load
Hold Up Time ≥ 25 ms @ 230 VAC & ≥ 6 ms @ 115 VAC, Full load
Rise Time < 100 ms
Overload Protection > 110 % of rated output current; Hiccup mode; Autorecovery type
Overtemperature Protection Power supply shuts down when the temperature of PCB below main transformer reaches typically 120°C;
Turns on only after the temperature falls below 90°C typically and AC power is recycled thereafter
Overvoltage Protection Hiccup mode when output over voltage occur; Autorecovery type
Output Short Circuit Protection Hiccup mode when output is shorted; Autorecovery type.
Operating Temperature - 25°C to + 70°C; De-rate linearly above 50°C from 100 % load at 50°C to 50 % load at 70°C.
-25°C to 0°C startup is guaranteed with specification deviation(Output ripple can be more than 10 % of the output voltage.)
Storage Temperature - 40°C to + 85°C
Cooling Natural convection cooled
Humidity 5 to 95 % RH, Non condensing
Altitude 2000 m
Dimension 35 x 90 x 60 mm ( W x H x D )
Weight < 150 gms
Mounting 35 mm DIN Rail
Vendor INDUSWELL
Type Industrial & Scientific
Sku RPS40-24-CE
Weight 0.15 kg
