TeSys D - suppressor module - RC circuit - 50...127 V ACTeSys D - suppressor module - RC circuit - 50...127 V AC

Rs. 2,480.00 + 18% GST Rs. 5,000.00
50
Low stock: 10 left
Quantity:
>

🚚 Item will be delivered on or before

Sku: LAD4RCG
Visa Mastercard American Express UPI
Main
Range TeSys
Device short name LAD4
Product or component type Suppressor module
Product compatibility 3P LC1D09...D38
4P LC1DT20...DT40
4P LC1D098...D258
CAD32, CAD50
Complementary
Mounting location Side
Mounting mode By clips
Suppressor technology RC circuit
[Uc] control circuit voltage 50...127 V AC
Maximum peak voltage 3 Uc
Product weight 0.012 kg
Environment
Standards IEC 60947-5-1
EN 60947-5-1
CSA C22.2 No 60947-5-1
UL 60947-5-1
GB/T 14048.5
Product certifications UL
CSA
IP degree of protection IP2X conforming to IEC 60529
Ambient air temperature for operation -25…55 °C
Ambient air temperature for storage -40…80 °C
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 1.100 cm
Package 1 Width 8.000 cm
Package 1 Length 4.000 cm
Package 1 Weight 14.000 g
Unit Type of Package 2 S01
Number of Units in Package 2 70
Package 2 Height 15.000 cm
Package 2 Width 15.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 1.210 kg
Unit Type of Package 3 P06
Number of Units in Package 3 1120
Package 3 Height 45.000 cm
Package 3 Width 60.000 cm
Package 3 Length 80.000 cm
Package 3 Weight 27.500 kg
Contractual warranty
Warranty (in months) 18
Vendor INDUSWELL
Type Industrial & Scientific
Sku LAD4RCG
Weight 0.5 kg
